19051
ECGX20MN IP65 Spiral Conduit Box Connector 20mm to M25 Black
The ECGX20MN IP65 Spiral Conduit Connector is designed to connect 20mm flexible spiral conduit to a junction box using an M25 metric thread. It features a shock-resistant technopolymer construction, self-locking conduit inlet, rotating upper section and pre-assembled locknut.
Key Features
- Suitable for 20mm flexible spiral conduit
- M25 metric thread
- Black finish
- IP65 rated
- Shock-resistant PP-based technopolymer construction
- Self-locking conduit inlet
- Rotating upper section
- Pre-assembled locknut
- V2 self-extinguishing grade to UL94
- Abnormal heat resistance up to 750°C
- Suitable for industrial and commercial applications
- Compliant with EN 61386-1, EN 61386-23 and UL 1696
Product Information
The ECGX20MN IP65 Spiral Conduit Box Connector provides a secure connection between 20mm flexible spiral conduit and junction boxes with an M25 metric thread.
Made from shock-resistant PP-based technopolymer, the connector is designed for reliable use in industrial and commercial electrical installations. The conduit inlet features a self-locking thread, while the rotating upper section helps make installation and positioning easier.
The connector is supplied with a pre-assembled locknut and offers V2 self-extinguishing performance in accordance with UL94. It also provides resistance to abnormal heat up to 750°C.
Technical Specification
| Specification | Details |
|---|---|
| Product Code | ECGX20MN |
| Product Type | Spiral Conduit to Box Connector |
| Conduit Size | 20mm |
| Thread Size | M25 |
| Thread Type | Metric |
| Colour | Black |
| IP Rating | IP65 |
| Material | Shock-Resistant PP-Based Technopolymer |
| Conduit Inlet | Self-Locking Thread |
| Upper Section | Rotating |
| Locknut | Pre-Assembled |
| Self-Extinguishing Rating | V2 to UL94 |
| Abnormal Heat Resistance | Up to 750°C |
| Standards | EN 61386-1, EN 61386-23, UL 1696 |
| EAN / Barcode | 8050880889525 |
| Pack Quantity | 25 |
| Pack Weight | 0.45kg |
| Outer Carton Quantity | 250 |
| Outer Carton Weight | 4.5kg |
| Outer Carton Barcode | 8057711594665 |
Product Details
| Brand | PEMCO | Datasheet | Download |
|---|
